Applied Analytics Tail Gas Probe V3Since 2014, we have been field-testing a major update to the probe design for our TLG-837 Tail Gas Analyzer — the most trusted H2S/SO2 ratio monitor in the sulfur recovery industry. We are excited to announce the official launch of DEMISTER Probe v3!
The New Isolation Valve
On previous probe versions, the ball valve allows the user to retract the probe from the process pipe to perform maintenance. In DEMISTER Probe v3, we introduced a bonnet-style shutoff valve directly in the probe head with which you can internally seal the process at the sample entrance port. This safe, quick method to access the sample flow cell completely eliminates the need to retract the probe during maintenance!Our case studies exceeded our own expectations: engineers reported that the maintenance procedure of cleaning the optics (recommended monthly) is 75% faster when using the isolation valve than when retracting the probe.
Redesigned Cooling Extensions
On the TLG-837, the cooling extensions increase the distance between the fiber optic collimators and the flow cell, protecting the optics from damage due to conductive heat transfer. Thanks to user feedback, we relocated the sealing o-rings from the probe head to the body of the removable cooling extension itself, making them much more accessible for routine inspections. Don't worry — the new cooling extensions retrofit into all of our previous DEMISTER Probe versions.
No other tail gas analyzer manufacturer takes the needs of the user as seriously as we do. We are now shipping the best version of the safest, most advanced tail gas analyzer in the world.
